YIHUA939D+-III 110W

1.939D+-III 110W this model can used for all soldering scenarios, it's special design for used for small work space 2. the machine have 2 clips ,can clip the baord, also have magnifying glass lamp,when your work place is dark or the board inside components is small need magnifying soldering and desoldering,then this machine is very convenience。

the soldering iron holder can fixed the machine case top,can save the work space

4. the soldering iron holder is Bakelite iron holder ,even if over 300 degree on the iron holder,also is no problems,and the iron holder have 08Btips cleaner ,it's very convernience for clean the tips, and the iron holder have solder wire standard on the iron holder back top, this way can save space ,also have 5 holes on the holder ,can used for put soldering iron tips,it's can easy find the things; There is a silicone gasket in the cleaning tank where the cleaning sponge is placed. When the soldering iron tip has tin dross, clean it in the cleaning tank and shake it, it can protect the soldering iron handle inside heater ,not easy to shake broke. 5. the soldering iron handle is new design,and the handle silicone line more thin,and more soft,when use it ,ti feel more comfortable 。

939D+-III have iron sleep function: sleep range:5mins,10 mins,15mins,20mins,30mins

7.939D+-III have 4 stage storage,CH1,CH2,CH3,CH4, can set different value for save, then next time you can easy to use it

it have Buzzer switch and temperature correction

• 9.Soldering iron power is 110W
• Technical data: Rated Voltage Range:220V-240V Rated Frequency:50Hz Operating Ambient Temperature:0〜40℃/32℉〜104℉
• Output power: 110W Temperature range:200〜480℃/392〜896℉
• Soldering iron: ESD design Display mode:Nixie LED

• 110W High-Power Soldering Station – Designed for reliable soldering and desoldering across a wide range of applications.
• Compact Space-Saving Design – Specially designed for small workspaces and professional electronics repair.
• Dual PCB Clips – Securely holds the circuit board for stable and convenient hands-free soldering.
• Built-in Magnifying Glass Lamp – Provides clear visibility for small components and detailed soldering work, especially in low-light conditions.
• Top-Mounted Iron Holder – Can be fixed on top of the machine case to maximize and save valuable workspace.
• Heat-Resistant Bakelite Iron Holder – Durable holder designed to safely withstand temperatures above 300°C.
• Integrated Tip Cleaner – Includes an 08B tip cleaner for quick and convenient soldering tip cleaning.
• Solder Wire Holder – Built into the rear top of the iron holder to keep solder wire organized and save space.
• 5 Tip Storage Holes – Conveniently stores spare soldering tips for quick access.
• Silicone-Protected Cleaning Tank – Helps reduce impact and vibration when cleaning the soldering tip, protecting the internal heater and extending handle durability.
• Ergonomic Silicone Handle – New-generation handle with a thinner, softer silicone cable for improved flexibility and comfortable operation.
• Iron Sleep Function – Selectable sleep times: 5 / 10 / 15 / 20 / 30 minutes to help improve tip life and energy efficiency.
• 4 Preset Memory Channels – CH1, CH2, CH3 and CH4 allow users to save different temperature settings for quick access.
• Buzzer ON/OFF Function – Allows convenient control of operating sound notifications.
• Temperature Correction Function – Enables temperature calibration for improved soldering accuracy.
• ESD-Safe Soldering Iron – Designed with ESD protection for sensitive electronic components.
• Nixie LED Display – Clear digital temperature display for easy monitoring.
• Wide Temperature Range – Adjustable from 200°C to 480°C (392°F to 896°F).
